NK Grade F40 Shipbuilding Steel Plate: High-Strength Hull Structural Material for Extreme Cold
Comprehensive technical data for NK Grade F40 shipbuilding steel plate according to Nippon Kaiji Kyokai rules, including chemical composition, mechanical properties, physical properties, international equivalents, and application guide.
Cutting, forming, welding (common shipbuilding processes); suitable for hot and cold forming with post-forming heat treatments if necessary.
- Phone : +8618037372205
- Email : [email protected]
- WhatsApp: Contact via Whtsapp
- WeChat: +8618037372205
NK Grade F40 Shipbuilding Steel Plate Introduction
NK Grade F40 is a high-strength hull structural steel plate classified by Nippon Kaiji Kyokai (ClassNK). It belongs to the normalized or TMCP (Thermo-Mechanical Controlled Process) high-strength structural steels for shipbuilding with a minimum yield strength of 390 MPa. The "F" designation indicates fine grain practice and guaranteed impact toughness down to -60°C.
- Excellent notch toughness at very low temperatures for critical applications in ice-class vessels and Arctic service.
- Good weldability and formability with controlled carbon equivalent (CEV) typically ≤ 0.40%.
- Delivered in normalized, quenched and tempered, or TMCP condition as agreed, with mandatory Charpy V-notch testing at -60°C (longitudinal, ≥41 J up to 50 mm thickness).
- Widely used for deck, shell plate, longitudinal strength members, and structural components in large container ships, bulk carriers, and offshore structures operating in cold environments.
NK Grade F40 Shipbuilding Steel Plate Chemical Composition
The chemical composition meets ClassNK requirements for F40 grade. Fine grain elements (Al, Nb, V, Ti) are added to achieve the required strength and low-temperature toughness. Carbon equivalent (CEV) is typically controlled to ensure good weldability.
| Element | Standard Value (max, %) | Remarks |
|---|---|---|
| C | ≤ 0.16 | Reduced to improve toughness and weldability |
| Si | ≤ 0.50 | Deoxidizer |
| Mn | 0.90 – 1.60 | Strength and toughness enhancer; upper limit may be adjusted for thicker plates |
| P | ≤ 0.025 | Phosphorus – impurity controlled |
| S | ≤ 0.025 | Sulfur – impurity controlled for through-thickness properties |
| Al (total) | ≥ 0.020 | Fine grain practice; acid soluble Al typically ≥ 0.015% |
| Nb | 0.02 – 0.05 | Grain refinement and precipitation strengthening |
| V | 0.05 – 0.10 | May be added in combination with Nb/Ti |
| Ti | ≤ 0.02 | Grain refinement and nitrogen fixation |
| Cu | ≤ 0.35 | Residual; may be specified lower for certain applications |
| Cr | ≤ 0.20 | Residual; may be increased for specific properties if agreed |
| Ni | ≤ 0.40 | Residual; higher levels can be agreed for improved toughness |
| Mo | ≤ 0.08 | Residual |
| N | ≤ 0.009 | Controlled to avoid strain aging; if Ti is present, sufficient to fix nitrogen |
NK Grade F40 Shipbuilding Steel Plate Physical Properties
Physical properties are typical for fine-grain structural steels with similar composition. These values are not specified in the ClassNK rule but are provided as engineering reference data for design calculations.
| Property | Typical Value | Unit | Test Condition / Remarks |
|---|---|---|---|
| Density (ρ) | 7850 | kg/m³ | Room temperature |
| Modulus of Elasticity (E) | 205 – 210 | GPa | Room temperature |
| Shear Modulus (G) | 79 – 81 | GPa | Calculated from E and ν |
| Poisson's Ratio (ν) | 0.29 – 0.30 | — | Room temperature |
| Thermal Expansion Coefficient (α) | 11.5 – 12.5 | ×10⁻⁶/K | Mean value 20 – 100°C |
| Thermal Conductivity (λ) | 45 – 55 | W/(m·K) | At 20°C |
| Specific Heat Capacity | 460 – 500 | J/(kg·K) | At 20°C |
| Electrical Resistivity (ρ_e) | 0.22 – 0.26 | Ω·mm²/m | At 20°C |
NK Grade F40 Shipbuilding Steel Plate Mechanical Properties
The mechanical properties below are based on ClassNK requirements for F40 grade plate in thicknesses ≤ 50 mm. For thicknesses > 50 mm, values must be agreed. Properties are verified in the delivery condition (N, TMCP or Q&T). Impact test temperature is -60°C.
| Property | Requirement Value | Unit | Test Condition / Remarks |
|---|---|---|---|
| Yield Strength (ReH) | ≥ 390 | MPa | Transverse or longitudinal; thickness ≤ 50 mm |
| Tensile Strength (Rm) | 510 – 650 | MPa | Thickness ≤ 50 mm |
| Elongation (A) | ≥ 20 | % | Gauge length 5.65√S₀; thickness ≤ 50 mm |
| Charpy V-Notch Impact (KV₂) | ≥ 41 (average) | J | Longitudinal, at -60°C; single value ≥ 70% of average |
| Charpy V-Notch Impact (KV₂) | ≥ 27 (average) | J | Transverse, at -60°C, if specified |
| Bend Test (d = 3a) | No cracks | — | 180° bend; d = mandrel diameter, a = specimen thickness |
NK Grade F40 Shipbuilding Steel Plate Fully Equivalent Standards and Alternative Grades
| Country / Region | Standard / Classification Society | Grade Designation | Remarks |
|---|---|---|---|
| International | IACS (International Association of Classification Societies) | F40 (or equivalent) | Most IACS members have an equivalent; use of F40 is widely harmonized |
| USA | American Bureau of Shipping (ABS) | EH40 | Equivalent yield strength (390 MPa) and -60°C toughness |
| UK | Lloyd's Register (LR) | FH40 | Same strength and impact test temperature (-60°C) |
| Norway/Germany | DNV | F40 | DNV F40 matches NK F40 in all criteria |
| France | Bureau Veritas (BV) | FH40 | FH40 designation indicates 390 MPa yield and -60°C Charpy |
| China | China Classification Society (CCS) | FH40 | Fully harmonized with IACS UR W11 |
| Korea | Korean Register (KR) | FH40 | Equivalent to NK F40 |
| Italy | RINA | FH40 | Same strength and low-temperature toughness class |
NK Grade F40 Shipbuilding Steel Plate Application Introduction
NK Grade F40 is specifically designed for primary hull structures in vessels operating in low-temperature environments, such as ice-class ships, LNG carriers, and Arctic offshore units. It is suitable for the most highly stressed regions like deck panels, sheer strakes, bilge strakes, and longitudinal girders. The excellent low-temperature toughness ensures resistance to brittle fracture even under dynamic loading conditions. The steel can be processed by standard shipyard methods: cutting, forming, and automatic welding. Preheating may be required for thick sections or when welding in cold climates, following approved welding procedures. Post-weld heat treatment (PWHT) is not mandatory unless specified by the classification rules for special applications.
Product Applications: Hull envelope: deck plates, side shell, bottom shell, and bulkheads, Longitudinal strength members: keel, sheer strake, bilge strake, Transverse structural elements: web frames, stringers, and floors, Offshore module support structures and crane pedestals, Ice belt reinforcement plates
Processed into products: Deck girders and deck longitudinals, Shell plating for ice-strengthened regions, Bilge keels and skegs, Hatch coamings and corner castings, Windlass foundations and hawse pipes (thick plates), Structural nodes shaped by plasma cutting and forming
Application industries: Shipbuilding (commercial and naval), Offshore oil & gas (fixed platforms, FPSO modules), Arctic engineering and ice-going vessels, LNG and LPG carrier construction, Heavy engineering and structural fabrication
NK Grade F40 Shipbuilding Steel Plate Similar or Proximate Alternative Materials
| Country / Region | Standard / Classification Society | Grade Designation | Remarks |
|---|---|---|---|
| Japan | NK Rules | NK F36 | Lower strength class (yield 355 MPa); same -60°C toughness; suitable where lower static loads are expected |
| Japan | NK Rules | NK E40 | Same strength (390 MPa) but impact temperature only -40°C; may be used if environment is less severe |
| International | IACS | F47 / F43 | Higher strength grades (420/430 and 460/470 MPa) with -60°C toughness; for weight-critical designs |
| EN | EN 10025-6 | S690QL / S690QL1 | Quenched and tempered steel with 690 MPa yield; higher strength but different welding and toughness requirements |
| ASTM | ASTM A709/A709M | Grade 50W [345W] / HPS 50W [345W] | Structural steel with lower strength; used for bridges and some offshore applications, not directly equivalent |
Notes:
Delivery Condition: NK F40 plates are typically supplied in either TMCP or normalized condition. TMCP is preferred for heavy plates (up to 50 mm) to achieve the strength-toughness balance without excessive alloying. Weldability: Carbon equivalent (CEV) is generally limited to ≤ 0.40% (for TMCP) or as agreed, to reduce cold cracking risk. Low-alloy fine-grain steel requires attention to heat input and interpass temperature; consumables should match the toughness requirements. Certification: Each plate is stamped with the NK mark, grade, heat number, and test results. Class surveyor or recognized inspection agency witness the tests as per NK rules. Thickness tolerance: As per classification rule part K or agreed specifications.
