ASTM A514 Grade E High-Strength Quenched & Tempered Steel Plate Introduction
ASTM A514 Grade E is a high-strength, quenched and tempered alloy steel plate designed for structural applications where weight savings and excellent weldability are crucial. This steel typically delivers a minimum yield strength of 100 ksi (690 MPa) in thicknesses up to 2.5 in., combining high tensile strength with good notch toughness at low temperatures. Key features include:
- Excellent strength-to-weight ratio, allowing lighter designs
- Low-temperature impact toughness down to -50 °F
- Good weldability with proper procedures
- Resistance to brittle fracture in demanding service conditions
Grade E is a nickel-chromium-molybdenum alloy with additions of vanadium, titanium and boron for fine-grain strengthening and hardenability. It is widely employed in mobile cranes, heavy-duty machinery, bridges, and offshore structures where high static and dynamic loads are encountered.
ASTM A514 Grade E High-Strength Quenched & Tempered Steel Plate Chemical Composition
The typical chemical composition of ASTM A514 Grade E according to ASTM A514/A514M is shown below. The steel is a Ni-Cr-Mo alloy with microalloying elements (V, Ti, B) to promote fine grain size and deep hardenability. Note: Unless otherwise specified, maximum limits apply. The values are based on heat analysis.
| Element | Standard Value (max unless range given) | Remarks |
|---|---|---|
| Carbon (C) | 0.12–0.20 | Heat analysis |
| Manganese (Mn) | 0.40–0.70 | Heat analysis |
| Phosphorus (P) | ≤ 0.025 | |
| Sulfur (S) | ≤ 0.025 | |
| Silicon (Si) | 0.20–0.35 | Heat analysis |
| Nickel (Ni) | 1.80–2.20 | |
| Chromium (Cr) | 1.40–1.80 | |
| Molybdenum (Mo) | 0.40–0.60 | |
| Copper (Cu) | ≤ 0.50 | Residual element |
| Vanadium (V) | 0.02–0.06 | Micro-alloying |
| Titanium (Ti) | 0.01–0.03 | Grain refinement |
| Boron (B) | 0.001–0.005 | Hardenability enhancer |
ASTM A514 Grade E High-Strength Quenched & Tempered Steel Plate Thermal and Electrical Physical Properties
Typical room-temperature physical properties of A514 Grade E are listed below. These values may vary slightly with heat treatment and actual composition. They are representative for engineering calculations.
| Property | Typical Value | Unit | Test Condition / Temperature |
|---|---|---|---|
| Density (ρ) | 7850 | kg/m³ | 20 °C |
| Elastic Modulus (E) | 207 | GPa | 20 °C |
| Shear Modulus (G) | 80 | GPa | Calculated, typical |
| Poisson's Ratio (ν) | 0.30 | - | 20 °C |
| Thermal Expansion Coefficient (α) | 11.7 | 10⁻⁶ / K | 20–100 °C |
| Thermal Conductivity (λ) | 42 | W/(m·K) | 100 °C |
| Specific Heat Capacity | 460 | J/(kg·K) | 20 °C |
| Electrical Resistivity (ρ_e) | 0.178 | µΩ·m | 20 °C |
ASTM A514 Grade E High-Strength Quenched & Tempered Steel Plate Mechanical Properties
The following mechanical properties are achieved in the quenched and tempered condition. All values are derived from ASTM A514/A514M. Yield strength and tensile strength depend on plate thickness. Impact testing is performed on Charpy V-notch specimens; typical requirement is 20 ft·lbf (27 J) at -50 °F (-45 °C) for longitudinal specimens.
| Property | Standard Required Value | Unit | Test Condition |
|---|---|---|---|
| Yield Strength (ReH) min | 100 (690) | ksi (MPa) | Thickness ≤ 2.5 in. (63.5 mm) |
| Yield Strength (ReH) min | 90 (620) | ksi (MPa) | Thickness > 2.5–4 in. (63.5–101.6 mm) |
| Yield Strength (ReH) min | 80 (550) | ksi (MPa) | Thickness > 4–6 in. (101.6–152.4 mm) |
| Tensile Strength (Rm) | 110–130 (760–895) | ksi (MPa) | Thickness ≤ 2.5 in. (63.5 mm) |
| Tensile Strength (Rm) | 105–130 (725–895) | ksi (MPa) | Thickness > 2.5–4 in. (63.5–101.6 mm) |
| Tensile Strength (Rm) | 100–130 (690–895) | ksi (MPa) | Thickness > 4–6 in. (101.6–152.4 mm) |
| Elongation (A) in 2 in. (50 mm) min | 18 | % | Thickness ≤ 2.5 in. (63.5 mm) |
| Elongation (A) in 2 in. (50 mm) min | 17 | % | Thickness > 2.5–4 in. (63.5–101.6 mm) |
| Elongation (A) in 2 in. (50 mm) min | 16 | % | Thickness > 4–6 in. (101.6–152.4 mm) |
| Charpy V-Notch Impact (KV) | ≥ 20 ft·lbf (27 J) | ft·lbf (J) | Longitudinal, -50 °F (-45 °C) |
| Bend Test (Diameter to Thickness Ratio) | d = 3t for plates up to 2.5 in., d = 4t for >2.5 in. | - | 180° bend |
ASTM A514 Grade E High-Strength Quenched & Tempered Steel Plate Fully Equivalent Material Standards and Replaceable Grades
| Country/Region | Standard | Grade | Remarks | |
|---|---|---|---|---|
| United States | ASTM A514/A514M | Grade E (A514Gr.E) | Direct standard; other suppliers may use dual certification to EN 10025-6 S690QL, but chemical composition may differ | |
| Europe | EN 10025-6 | S690QL / S690QL1 | Closest European equivalent in strength and toughness, but minimum yield 690 MPa for thicknesses ≤50 mm; chemistry differs (C, Mn, etc.). Not an exact match. | Substitution requires careful review of chemical and mechanical specifications |
ASTM A514 Grade E High-Strength Quenched & Tempered Steel Plate Application Introduction
ASTM A514 Grade E is engineered for demanding structural applications where high strength, good low-temperature toughness, and reliable weldability are essential. Its high yield-to-tensile ratio allows engineers to reduce section thickness and weight without sacrificing safety. Typical applications sectors include:
Product Applications: All-terrain and crawler crane booms and outriggers, Bridge girders and orthotropic deck plates, Mining dump truck frames and excavator booms/arms, Heavy-duty trailers and transport equipment, Offshore platform structural nodes and braces, High-pressure gas cylinders and spherical storage tanks
Processed into products: Welded H-beams, box sections and built-up girders, Crane telescoping boom sections and pivot pins, Load-bearing machine frames and chassis, Structural stiffeners and splice plates, Lifting lugs, pad eyes and shackles, Riprap and cut-resistant wear plates (where combined with hardfacing)
Application industries: Construction and heavy civil engineering (bridges, stadiums, high-rise structures), Mobile crane and lifting equipment manufacturing, Mining and earth-moving machinery, Offshore and marine structures (jack-up rigs, crane pedestals), Pressure vessel and boiler fabrication (when certified to A517), Military and defense vehicle armor/structural parts
ASTM A514 Grade E High-Strength Quenched & Tempered Steel Plate Similar/Alternative Substitute Material Recommendations
| Country/Region | Standard | Grade | Remarks |
|---|---|---|---|
| United States | ASTM A514/A514M | Grade Q | Another A514 grade with similar strength and toughness; chemistry modified for improved weldability or properties. Often interchangeable with Grade E in some applications. |
| United States | ASTM A517/A517M | Grade E (A517Gr.E) | Similar chemistry and properties but intended for pressure vessel applications (A517); yield strengths match A514. |
| United States | ASTM A709/A709M | Grade 100/100W | High-strength structural steel for bridges; Grade 100 has similar yield strength (100 ksi) but different chemistry and toughness requirements. |
| Europe | EN 10025-6 | S690Q/QL/QL1 | Closest European high-strength Q&T steel; yield 690 MPa, impact tested at -20 °C or -40 °C. Used in mobile cranes and structural applications. |
| Japan | JIS G 3128 | SHY 685 | High yield strength steel for welded structures; minimum yield 685 MPa; often used as a substitute but chemistry and toughness differ. |
Notes:
- Welding of A514 Grade E requires strict heat input control and preheat/interpass temperature management to avoid hydrogen cracking and maintain heat-affected zone toughness. Low-hydrogen electrodes and practices are mandatory.
- Post-weld heat treatment (PWHT) is generally not recommended because it can degrade the carefully balanced quenched and tempered properties. If stress relief is unavoidable, the temperature and time must be closely controlled as per AWS D1.1 or equivalent.
- The Charpy impact values listed are minimum requirements; actual values are often significantly higher, especially when fine-grain practice and controlled rolling are employed.
- Plates can be ordered with additional testing (ultrasonic, Z-direction properties) for critical applications.
- This data is based on ASTM A514/A514M standards and typical manufacturer information. Always consult the material test certificate for specific lot properties.
