JIS G3459 SUS 317L TP Introduction
JIS G3459 SUS 317L TP is an austenitic stainless steel pipe designed for machine and structural applications. It contains low carbon (max 0.030%) and higher molybdenum (3-4%) compared to 304/304L, providing excellent pitting and crevice corrosion resistance in chloride environments. This grade offers good weldability and is used in chemical processing, marine, and high-temperature applications. Key features include:
- Superior corrosion resistance in acidic and chloride media
- Excellent intergranular corrosion resistance after welding
- Good high-temperature strength
JIS G3459 SUS 317L TP Chemical Composition
Chemical composition as per JIS G3459 for SUS 317L TP. Maximum limits unless range given. Note: Low carbon to prevent sensitization during welding.
| Chemical Element | Standard Value | Remarks |
|---|---|---|
| Carbon (C) | ≤0.030 | Low carbon for improved intergranular corrosion resistance |
| Silicon (Si) | ≤1.00 | |
| Manganese (Mn) | ≤2.00 | |
| Phosphorus (P) | ≤0.045 | |
| Sulfur (S) | ≤0.030 | |
| Nickel (Ni) | 11.00 - 15.00 | Enhances ductility and corrosion resistance |
| Chromium (Cr) | 18.00 - 20.00 | Key element for corrosion resistance |
| Molybdenum (Mo) | 3.00 - 4.00 | Improves pitting and crevice corrosion resistance |
JIS G3459 SUS 317L TP Physical Properties
Typical physical properties for fully annealed 317L stainless steel. Values may vary slightly with product form and condition.
- Density, elastic modulus, etc.
| Property | Typical Value | Unit | Test Condition |
|---|---|---|---|
| Density (ρ) | 8.0 | g/cm³ | 20°C |
| Elastic Modulus (E) | 200 | GPa | 20°C |
| Shear Modulus (G) | 77 | GPa | 20°C |
| Poisson's Ratio (ν) | 0.28 | - | 20°C |
| Thermal Expansion Coefficient (α) | 16.0 | µm/m·°C | 20-100°C |
| Thermal Conductivity (λ) | 14.0 | W/m·K | 100°C |
| Specific Heat Capacity | 500 | J/kg·K | 20°C |
| Electrical Resistivity (ρ_e) | 0.74 | µΩ·m | 20°C |
JIS G3459 SUS 317L TP Mechanical Properties
Mechanical properties at room temperature for pipes according to JIS G3459. Test specimen: Longitudinal strip, for wall thickness ≤8mm, elongation measured on gauge length 50mm.
| Property | Standard Requirement | Unit | Test Condition |
|---|---|---|---|
| Tensile Strength (Rm) | ≥480 | MPa | Room temperature |
| Yield Strength (ReH / Rp0.2) | ≥175 | MPa | Room temperature, 0.2% offset |
| Elongation (A) | ≥35 | % | Longitudinal, gauge 50mm, wall ≤8mm |
| Hardness | ≤90 HRB or ≤200 HV | - | Optional, for reference |
JIS G3459 SUS 317L TP Exact Equivalent Standards and Replaceable Grades
| Country/Region | Standard | Grade | Remarks |
|---|---|---|---|
| Japan | JIS G3459 | SUS 317L TP | Original standard |
| USA | ASTM A312/A312M | TP317L | Seamless and welded pipe for high-temperature service |
| Europe | EN 10216-5 | X2CrNiMo18-15-4 (1.4438) | Seamless steel tubes for pressure purposes, austenitic |
| China | GB/T 14976 | 022Cr19Ni13Mo3 (S31703) | Stainless steel seamless tubes for fluid transport |
| International | ISO 1127 | X2CrNiMo18-15-4 | Stainless steel tubes |
JIS G3459 SUS 317L TP Application Introduction
SUS 317L TP pipes are ideal for environments requiring high resistance to pitting and crevice corrosion. Typical applications include:
- Chemical and petrochemical plants
- Heat exchangers and condensers
- Pulp and paper production
- Flue gas desulfurization (scrubbers)
- Marine equipment
Product Applications: Pipes for corrosive fluid handling, Heat exchanger tubes, Desulfurization piping, Pulp bleach lines
Processed into products: Nozzles, Fittings, Flanges, Valve bodies, Pressure vessel shells, Steam piping
Application industries: Chemical Processing, Oil & Gas, Marine, Pulp & Paper, Food & Beverage, Power Generation
JIS G3459 SUS 317L TP Similar or Alternative Material Recommendations
| Country/Region | Standard | Grade | Remarks |
|---|---|---|---|
| Japan | JIS G3459 | SUS 317 TP | Higher carbon (≤0.08%), less weldable; similar corrosion resistance |
| Japan | JIS G3459 | SUS 316L TP | Lower Mo (2.0-3.0%), slightly lower pitting resistance |
| USA | ASTM A312 | TP316L | Austenitic with Mo, common alternative where 317L overkill |
| Europe | EN 10216-5 | X2CrNiMo17-12-2 (1.4404) | Lower Mo, similar mechanical properties |
Notes:
Welding: Excellent weldability with standard processes (TIG, MIG, SMAW). Post-weld annealing not required for thin sections. Corrosion Resistance: Resistant to sulfuric and phosphoric acids, seawater, and chloride stress corrosion cracking (though susceptible under extreme conditions). Heat Treatment: Solution anneal at 1040-1120°C, rapid cooling. Pickling/Passivation: Recommended after fabrication to restore surface integrity.
